The application for the design and calculation of electronic circuits using operational amplifiers.
The application contains the following guides and calculators:
Amplifiers
- Non-inverting operational amplifier
- Inverting operational amplifier
- Inverting amplifier with T-bridge in OS
- Differential amplifier
- Voltage repeater
Converters
- Voltage-to-current converter with non-inverting input
- Voltage to current converter with inverting input
- Voltage to current converter with differential input
Adders and substactors
- Inverting adder
- Addition-subtraction circuit
- Non-inverting adder
Attenuators
- Non-inverting attenuator
- Inverting attenuator
Active Filters
- First-order non-inverting low-pass filter
- First-order inverting low-pass filter
- Non-inverting high-pass filter
- Inverting high pass filter
- Gyrator
Integrators and differentiators
- Voltage integrator
- Sum integrator
- Difference integrator
- Double integrator
- Voltage differentiator
Logarithmic and exponential amplifiers
- Diode-based logarithmic amplifier
- Transistor-based logarithmic amplifier
- Diode exponential amplifier
- Exponential transistor amplifier
The app can switch between a light and dark theme, depending on the user's preferences.
The content of this application is constantly updated when new versions are released.
