VIDHISHA SMART LIGHT SWITCH

About this App
(A) Vidhisha Smart Light switch Android app to control 3 channel, 4 channel and 8 channel relay module via Bluetooth.
Vidhisha smart light switch App is android application which is used to control 3 channel,4 channel and 8 channel relay module via Bluetooth with Bluetooth serial communication module support HC-05 or HC-06.
(B) Control your electronic project with our Android App using Bluetooth.
Control your electronic project with our Android App. This app communicates using Bluetooth to a HC-05 or HC-06 Bluetooth module in your project.
----------------------------------------
About the Device
(A)This device is designed to control the lights through Android App /manually, to turn On/Off every single channel separately or all of them together.

Note:-
1. For safety turn off the main power supply while Installation.
2. In two ways switch connect only one switch, Remove other switch.
3. Device can be operated by both the modes: - (a) Manually (b) Android App mode, Keep
the manual switch “off”.
4. Do not overload the switch.
5. If any problem during Installation mail at [email protected]

Installation Process:-
1. Switch off the main power supply.
2. Open the switch board.
3. Locate the phase point and connect the red wire of the device to it.
4. Locate the neutral point and connect the black wire of the device to it.
5. Connect all yellow wires to the light switches as shown in the diagram.
6. Close the switch board by trucking/Pushing all the wires of the sensor unit inside the board.

Specifications:-
 Operating voltage 220V-240V (AC)
 Frequency -50Hz
 Load capacity-1000W
 Bluetooth App control switch.
 Only five wire to hook up for three lights and six wire to hook up for four lights.
 No requirement of external power supply.

Features:-

 Operate through mobile App control as well as manually.
 Totally shock proof.
 Fast and Easy Installation (No need to Re-wiring or alteration).
 Save electricity (Reduce your energy bill by switching off all the lights when no need).
 Fluctuation less switching for lights.
 24*7 good performance.
