Short Transmission Line
Medium Transmission Line
Long Transmission Line
The phasor diagrams, supported with visual aids, offer a simple solution for the short transmission line. The medium transmission line solves the nominal pi model and nominal T model simultaneously, displaying values on a single result screen for easy reference. For the long transmission line, you can quickly obtain values such as attenuation constant, characteristic impedance, etc. in just 5 steps, within seconds.
You can calculate all the parameters of transmission lines in 5 steps. Phasor-Complex transformations and the units of the input line values are made user-friendly, and some auxiliary tools have been added to facilitate this process.
